Bonamia sp.

Clinical pathology

Bonamiosis is a lethal infection of the haemocytes (picture 1) of flat oysters sometimes accompanied by yellow discoloration and extensive lesions on the gills and mantle. However, most of the infected oysters appear normal. Histologically, lesions occur in the connective tissue of the gills, mantle, and digestive gland. This intrahaemocytic protozoan quickly becomes systemic with overwhelming numbers of parasites coinciding with the death of the oysters. Although the life cycle outside the host is unknown, it has been possible to transmit the disease experimentally in the laboratory by cohabitation or inoculation of purified parasites. The species Bonamia ostreae and B. exitiosa are observed in Europe.

Picture 1 : Bonamia ostreae cells inside haemocytes and free in the connective tissue surrounding the digestive gland of a flat oyster  Ostrea edulis (H&E staining).

Agent description

Bonamia ostreae and B. exitiosa are protistan parasites of the phylum Haplosporidia responsible for bonamiosis also named microcell disease or haemocyte disease of flat oysters Ostrea edulis in Europe. B. exitiosa has been observed in flat oysters Ostrea edulis from Galicia (Spain) in 2007.

Screening techniques for the pathogen

Imprints

Tissue imprints (picture 2) can be made using oyster spat or heart ventricle or gills from live adult hosts. Bonamia ostreae appears as small spherical or ovoid organisms (2-5 µm wide) inside haemocytes. However, the parasite might also occur extracellularly. Using Wright, Wright-Giemsa or equivalent stain (e.g., Hemacolor, Merck; Diff-QuiK, Baxter) these parasites show a basophilic cytoplasm and an eosinophilic nucleus. Multinucleated cells can be observed (picture 2).

Picture 2 : Heart imprint of European flat oyster Ostrea edulis showing free cells and some diplocaryotic and a multinucleate cell of  Bonamia ostreae (Hemacolor® staining).

Histopathology

Histopathology should be performed on tissue sections that include gills, digestive gland, mantle, and gonad and stained with hematoxylin and eosin. In infected oysters, parasites can be observed as very small cells of 2-5 µm wide, within the haemocytes or freely in connective tissue (picture 3) or sinuses of gill, gut and mantle epithelium, often associated with intense inflammatory reaction.

Picture 3: Bonamia exitiosa microcells (arrows) inside haemocytes in the connective tissue from a flat oyster from Galicia, Spain ( slide courtesy of Antonio Villalba, Centro de Investigacións Mariñas, Conselleria de Pesca e Asuntos Marítimos da Xunta de Galicia, Vilanova de Arousa, Spain)

Tissue imprints appear less reliable than histopathology for the detection of the parasite in case of low level of infections. However, tissue imprints are more rapid and less expensive than histopathology (cost for one individual is estimated at about 5 € and 20 € -including personal cost- respectively).

PCR

Two conventional PCR protocols with two different primer pairs targeting the SSU rDNA have been developed for Bonamia ostreae: the first one uses the primer pair Bo-Boas (Cochennec et al. 2000) and the second one the primer pair CF-CR (Carnegie et al. 2000). Based on target DNA sequence similarity, the first assay should amplify all microcell haplosporidians and the second one at least Bonamia ostreae and B. exitiosa. These assays have not been validated directly against one another but they appear to be roughly equivalent in sensitivity. PCR developed by Cochennec et al. (2000) has been compared to histopathology and cytology together (Balseiro et al. 2006). Sensitivity of PCR was 92% (between 64 and 69% for histological methods together) and specificity of PCR was estimated between 85 and 90% (97% for histological methods together).

Several real-time PCR assays have been developed such as: Taqman® PCRs for the detection of Bonamia sp. (Marty et al. 2006, Corbeil et al. 2006), SYBR Green PCR for the detection of B. ostreae alone (Robert et al. 2009), or for the detection and discrimination of B. ostreae and B. exitiosa (Ramilo et al. 2013). This latter one is the real-time PCR currently recommended by EU decision 2015/1554. It has been compared to histology and conventional PCR-RFLP (Cochennec et al. 2000) on a set of flat oyster (N=137) and showed an improved sensitivity. However, estimated specificity values suggest the possible occurence of false positives (Estimated sensitivity of the real-time PCR was 99% for B. ostreae and 100% for B. exitiosa, estimated specificity was 72% for B. ostreae and 77% for B. exitiosa.). Particular attention should be given to establish the Ct threshold above which a PCR signal should be considered as positive or negative when implementing this method.

To facilitate the monitoring of regulated diseases of flat oysters, the EURL has recently developed:

- a Taqman® PCR for the detection of Bonamia sp and Marteilia refringens in one step. This Taqman® PCR targets the 18S rDNA gene of both parisites. It was compared to the conventional PCR (Cochennec et al. 2000) on a set of 349 flat oysters. Both methods showed equivalent performances (Canier et al. in prep). The Taqman® PCR was evaluated by the EURL in the context of an Inter Laboratory Comparison test in 2017 by 17 European laboratories and showed good sensibility, specificity and reproducibility performances. The report is available under the NRL section (2017-ILC-01).

- Taqman® PCR for the detection and discrimination of B. ostreae and B. exitiosa. This Taqman® PCR  targets the actin gene of both parasites  and was also evaluated  in the context of an Inter Laboratory Comparison test in 2019 by 17 European laboratories. The new PCR  showed good sensibility, specificity and reproducibility performances. The report is available under the NRL section (2019-ILC-01).



The following standard operating procedures are available on the "SOPs and quality" page:

-          The conventional  PCR-RFLP for Bonamia spp detection and species characterisation (Cochennec et al. 2000)

-          The real-time Taqman® PCR for the detection of  Marteilia refringens and Bonamia sp. (EURL)

-          The real-time Taqman® PCR for the detection of Bonamia ostreae and Bonamia exitiosa (EURL)

Confirmatory techniques for diagnosis

In case of first detection in a new place or a new host, the EURL provides assistance for confirmatory diagnosis and further characterization. Please visit the Assistance page (Main-activities/Assistance) for details on how to send your samples.

PCR

Some of the PCR protocols previously described in the section “screening techniques”, can be used as confirmatory techniques: the real-time SYBR Green PCR for the detection of B. ostreae and B. exitiosa (Ramilo et al. 2013), the real-time Taqman® PCR for the detection of Bonamia ostreae and Bonamia exitiosa (EURL). The conventional PCR (Cochennec et al. 2000)  is not species specific, however, a protocol of RFLP can be applied on PCR products to differentiate Bonamia ostreae, B. exitiosa and B. roughleyi (Cochennec et al. 2003; Hine et al. 2001).

Standard operating procedures for the conventional PCR-RFLP (Cochennec et al. 2000) and the real-time Taqman® PCR (EURL) are available on the "SOPs and quality" page

ISH

Two  in situ hybridization (ISH) protocols have been developed. The first one (Cochennec et al. 2000) uses a 300 bp digoxigenin-labeled probe produced by PCR and using primer pairs Bo-Boas (picture 4) and the second one (Carnegie et al. 2003) uses three fluorescein-labeled oligonucleotide probes (UME-BO-1, UME-BO-2 and UME-BO- 3). The probe Bo-Boas is able to detect Haplosporidium nelsoni in  Crassostrea virginica, Bonamia exitiosa in Ostrea chilensis but not Mikrocytos mackini in C. gigas. The specificity of the oligoprobe cocktail UME-BO-1, 2 and 3 has been tested and proved against H. nelsoni but this ISH assay probably detects other microcells including at least B. exitiosa.

Picture  4 : ISH reaction with the digoxygenin-labeled probe used on infected gill of Ostrea edulis showing Bonamia cells (in blue) inside the connective tissue (Bismarck Brown counterstain).

In situ hybridization can help to detect early infection which is more difficult to detect in traditional histological sections.

TEM

Transmission electron microscopy is time consuming and can not be applied in routine but is recommended when Bonamia like parasites are described in a new host species. Moreover, transmission electron microscopy can help to differentiate B. ostreae from other members of this genus like B. exitiosa.

Different stages including uninucleate, diplocaryotic and plasmodial stages have been reported. Intracellular structures include mitochondria, haplosporosomes, Golgi apparatus and persistent intranuclear microtubules.

Picture 5: TEM micrograph showing two Bonamia ostreae cells inside an haemocyte of Ostrea edulis heart tissue. Note the lipid bodies (in black) and the large "vacuoles" (= mitochondria). Nucleus and cytoplasm have the same image grey density and the former can hardly be visible at this magnification.

Dense forms of  Bonamia ostreae are denser, slightly smaller in size in comparison to  Bonamia exitiosa, have less haplosporosomes, mitochondrial profiles and lipoid bodies per ultrastructure section, and have larger tubulo-vesicular mitochondria (picture 5) than B. exitiosa. In addition, dense forms of Bonamia ostreae lack nuclear membrane-bound Golgi/nuclear cup complexes and a vacuolated stage (Hine et al. 2001).

Sequencing

Sequencing is recommended as one of the final steps for confirmatory diagnostic. Targeted regions are SSU rDNA and ITS1. Obtained sequences should be compared with available ones in gene banks. Sequencing needs to be used for species confirmation between Bonamia ostreae and B. exitiosa.

What should we do for diagnosis at suspicion?

In some cases, highly infected oysters might present some gill indentations. When suspected,  Bonamia sp. can be detected by heart or gill imprints. In parallel, pieces of gill can be fixed in ethanol for PCR analysis and a section of oysters should be fixed in Davidson’s fixative for histological examination.

EU-legislation related to techniques

Bonamia ostreae is listed by the EU Directive 2006/88/EC as a non exotic pathogen. Bonamia exitiosa is listed by the EU Directive 2006/88/EC as exotic pathogen. B. ostreae and B. exitiosa are listed in the  Commission implementing regulation 2018/1882 in categories C+D+E.

Commission implementing decision 2015/1554 lay down rules for the application of Directive 2006/88/EC as regards requirements for surveillance and diagnostic methods for B. ostreae.

OIE recommendations related to techniques

B. ostreae and B. exitiosa are listed by the OIE Manual of Diagnostic Tests for Aquatic Animals (2009 version) and by the Aquatic Animal Health Code (2009 version).

The OIE recommends:

  • Tissue imprints, histopathology and PCR for surveillance
  • Tissue imprints and PCR for presumptive diagnostic
  • PCR & sequencing and transmission electron microscopy for confirmatory diagnostic

OIE Reference Laboratory

: Ifremer, laboratoire LGP, Av. de Mus de Loup, 17390 La Tremblade, FRANCE

: Dr Isabelle Arzul, e-mail: iarzul@ifremer.fr

Assessment

The tests are discussed at the annual European EURL/NRL meetings. Use the methods according to the table below for screening and confirmation.

Pathogen

Screening technique (well established)

Confirmatory technique (well established)

Evaluation

Bonamia sp.

Histology, imprint, PCR

PCR, DNA sequencing, ISH, TEM

Histology, imprint and ISH are only genus specific

References

Abollo E., Ramilo A., Casas S.M., Comesaña P., Cao A., Carballal M.J. & Villalba A. (2008). First detection of the protozoan parasite Bonamia exitiosa (Haplosporidia) infecting flat oyster Ostrea edulis grown in European waters. Aquaculture, 274 : 201-207

Balseiro P., Conchas R.F., Montes J., Gomez-Leon J., Novoa B. and A. Figueras (2006). Comparison of diagnosis techniques for the protozoan parasite Bonamia ostreae in flat oyster Ostrea edulis. Aquaculture 261 (4): 1135-1143.

Carnegie, R. B., Barber, B. J., Culloty, S. C., Figueras, A. J., and Distel, D. L. (2000). Development of a PCR assay for detection of the oyster pathogen Bonamia ostreae and support for its inclusion in the Haplosporidia. Diseases of Aquatic Organisms 42(3): 199-206.

Carnegie, R. B., Barber, B. J., and Distel, D. L. (2003). Detection of the oyster parasite Bonamia ostreae by fluorescent in situ hybridization. Diseases of Aquatic Organisms 55(3): 247-252.

Cochennec, N., Le Roux, F., Berthe, F., and Gerard, A. (2000). Detection of Bonamia ostreae based on small subunit ribosomal probe. Journal of Invertebrate Pathology 76(1): 26-32.

Cochennec Laureau, N., Reece, K. S., Berthe, F. C. J., and Hine, P. M. (2003). Mikrocytos roughleyi taxonomic affiliation leads to the genus Bonamia (Haplosporidia). Diseases of Aquatic Organisms 54(3): 209-217.

Corbeil, S., Arzul, I., Diggles, B., Heasman, M., Chollet, B., Berthe, F.C.J., Crane, M.S., 2006a. Development of a TaqMan PCR assay for the detection of Bonamia species. Diseases of Aquatic Organisms 71, 75-80.

Hine, P. M., Cochennec Laureau, N., and Berthe, F. C. J. (2001). Bonamia exitiosus n. sp (Haplosporidia) infecting flat oysters Ostrea chilensis in New Zealand. Diseases of Aquatic Organisms 47(1): 63-72.

Marty, G.D., Bower, S.M., Clarke, K.R., Meyer, G., Lowe, G., Osborn, A.L., Chow, E.P., Hannah, H., Byrne, S., Sojonky, K., Robinson, J.H., 2006. Histopathology and a real-time PCR assay for detection of Bonamia ostreae in Ostrea edulis cultured in western Canada. Aquaculture 261, 33-42.

Ramilo, A., Navas, J.I., Villalba, A., Abollo, E., 2013. Species-specific diagnostic assays for Bonamia ostreae and B. exitiosa in European flat oyster Ostrea edulis: conventional, real-time and multiplex PCR. Diseases of Aquatic Organisms 104, 149-161.

Robert, M., Garcia, C., Chollet, B., Lopez-Flores, I., Ferrand, S., Francois, C., Joly, J.P., Arzul, I., 2009. Molecular detection and quantification of the protozoan Bonamia ostreae in the flat oyster, Ostrea edulis. Molecular and Cellular Probes 23, 264-271.
